INTRAflex XT - Entrance Matting

by INTRAsystems

Download Add to collection

Description

Heavy-duty recessed aluminium entrance matting with removable sections for ease of cleaning and maintenance.

Suitable for internal and external applications
Wide range of rubber/brush/fibre inserts available
Heel-proof open or closed construction
Suitable for the highest traffic areas
Ideal for use with a Waterlogic base or mat well void as it can be rolled for ease of cleaning
Perfect for cut-into-flooring designs

Object Data

1 Revision

Last Updated

02/03/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Installation Guide

Product Literature

Product Data Sheet

Object metadata

_AuthorJack Yellop
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
_Object User Guidewww.bimstore.co/product/files/documents/2019/04/12/intrasystems-userguide-v11.pdf
Accessibility Performancen/a
ArrangementInset internal or external
Assembly CodeE2010
Asset TypeFixed
Base ColourAnodised to any RAL colour
Base MaterialAluminium
BIM Object NameINTRASystems_EntranceMatting_INTRAflexXT
Classification NameUniclass2015
Classification ValuePr_35_57_11_26
Code Performancen/a
ColorAluminium
Constituents100% recycled aluminium profiles with flexible connectors , choice of rubber, brush, polyamide or polypropylene inserts.
ConstructionOpen or Closed
Created Byinfo@intrasystems.co.uk
Created On2019-03-11T09:00:00
Default Elevation1219 mm
DescriptionAt the forefront of Entrance Matting design and innovation, this product has been used extensively throughout the UK at high profile locations, providing optimum durability, performance and aesthetics.
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturewww.bimstore.co/products/intraflexxt-entrance-matting/document/product-literature
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
Environmental Product Declaration100% Recycled aluminium
Expected Life15
Features100% recycled aluminium. / Full range of brush, rubber and fibre inserts available for internal and external applications./ Fully rollable for ease of cleaning and maintenance./ Heel-proof open or closed construction. / Optimum dirt and moisture removal.
FinishAluminium
Graden/a
Height17 mm
Ifc Export AsIfcCovering IfcCovering IfcCovering
Ifc Export TypeIfcCoveringTypeEnum.FLOORING
Insert Colour OptionsElite polyamide - 608 Black, 607 Anthracite, 606 Grey, 602 Blue, 605 Brown, 609 Purple, 610 Turquoise, 604 Coco, 601 Red. Premier polyamide - 007 Anthracite, 014 Grey. Polypropylene - 443 Anthracite, 451 Grey. Rubber - ribbed, multidirectional. Brush.
Integral AccessoriesPolypropylene ribbed fibre (colour)/ polyamide fibre (colour) / ribbed rubber/ brush or combination of inserts.
KeynoteM50
Linking JointsSynthetic Connection Splines
ManufacturerINTRAsystems
Manufacturer NameINTRAsystems
MaterialHeavy Duty Aluminium
Matting Height19mm
Matwell Frame FinishMill finish as standard. Anodized finish in any RAL colour available to special order.
ModelINTRAflex XT
Model Numbern/a
Model ReferenceINTRAFlex XT
Module Width29.5
NBS DescriptionEntrance matting
NBS Noten/a
NBS Object NameINTRASystems,Entrance matting
NBS Office Master Tagn/a
NBS Reference45-35-35/420
Nominal Depth0 mm
Nominal Height17 mm
Patternn/a
Production Year2019
Radiusn/a
Referenced Standardn/a
Replacement Costn/a
Rubber MaterialIntraSytems_RubberMaterial_Rubber
ShapeRectangular
Sizen/a
Spare Partsn/a
Surface Insert OptionsRubber, Polyamide fibre, Polypropylene fibre, Brush.
Temperature ResistanceAluminium resistance: -50°C to +90°C.
Traffic TypeHeavy / Extreme
Type CommentsRecessed Entrance Mat System
Type NameINTRAFlex XT
URLwww.intrasystems.co.uk/products/intraflex-xt/
Warranty Description10 Performance Guarantee, subject to correct cleaning and maintenance procedures being carried out
Warranty Duration Laborn/a
Warranty Duration Partsn/a
Warranty Duration UnitYears
Warranty Guarantor Laborwww.intrasystems.co.uk/products/intraflex-xt/
Warranty Guarantor Partswww.intrasystems.co.uk/products/intraflex-xt/
Weight18kg/m²

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
