Grohe - Grohtherm 800 Thermostat - 34755000

by GROHE

Download Add to collection

Description

Grohtherm 800
Thermostatic shower mixer 1/2„
wall mounted
GROHE StarLight chrome finish
GROHE SafeStop safety button at 38°C
GROHE SafeStop Plus optional temperature limiter at 43°C included
GROHE TurboStat compact cartridge with wax thermoelement
integrated mixed water shut off
volume handle with GROHE EcoButton (economy button with individually adjustable economy stop)
ceramic headpart 1/2", 180°
shower bottom outlet 1/2„
built-in non return valves
dirt strainers
protected against backflow
without connection unions
min. recommended pressure 1.0 bar
GROHE EcoJoy technology for less water and perfect flow

Object Data

1 Revision

Last Updated

13/01/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

_AuthorIan Holmes
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeC1030
Asset TypeFixed
BIM Object NameGrohe_PlumbingFixtures_Thermostat_Grohtherm800_34755000
Classification NameUniclass2015
Classification ValuePr_40_20_87_81
Code Performancen/a
Cold Water Connection Diameter10 mm
ColorSilver
Constituentsn/a
Created Byinfo-uk@grohe.com
Created On2019-12-05T09:00:00
CWFU4.5
Default Elevation0 mm
DescriptionGrohtherm 800 Thermostatic shower mixer 1/2„ wall mounted GROHE StarLight chrome finish GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C included GROHE TurboStat compact cartridge with wax thermoelement integrated mixed water shut off volume handle with GROHE EcoButton (economy button with individually adjustable economy stop) ceramic headpart 1/2", 180° shower bottom outlet 1/2„ built-in non return valves dirt strainers protected against backflow without connection unions min. recommended pressure 1.0 bar GROHE EcoJoy technology for less water and perfect flow
Documentation Certificateswww.grohe.com/
Documentation Installation Guidewww.grohe.com/
Documentation Literaturewww.grohe.com/
Documentation Maintenancewww.grohe.com/
Documentation Technicalwww.grohe.com/
Duration UnitYears
EcojoyYes
Expected Life0
FeaturesGrohtherm 800 Thermostatic shower mixer 1/2„ wall mounted GROHE StarLight chrome finish GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C included GROHE TurboStat compact cartridge with wax thermoelement integrated mixed water shut off volume handle with GROHE EcoButton (economy button with individually adjustable economy stop) ceramic headpart 1/2", 180° shower bottom outlet 1/2„ built-in non return valves dirt strainers protected against backflow without connection unions min. recommended pressure 1.0 bar GROHE EcoJoy technology for less water and perfect flow
FinishStainless Steel
Graden/a
Hot Water Connection Diameter10 mm
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe
Manufacturer NameGrohe
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialStainless Steel
ModelThermostat - GRT 800 THM shower exp 1/2"
Model Number34755000
Model ReferenceThermostat - GRT 800 THM shower exp 1/2"
NBS DescriptionShower mixers
NBS Object NameGrohe - Shower mixers
NBS Office Master Tagn/a
NBS Reference45-35-70/335
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Percentage Of Recycled Contentn/a
Product Documentation Linkn/a
Production Year2019
Product Page URLn/a
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments34755000
Type Name34755000
URLwww.grohe.com
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partsinfo-uk@grohe.com
