Grohe - Euphoria - 310 Shower System - 26849000

by GROHE

Download Add to collection

Description

consisting of:
horizontal swivable 450 mm shower arm
exposed thermostat with Aquadimmer function
allows change between:
head shower Rainshower Mono 310 (26 562)
spray pattern: GROHE PureRain
with ball joint, rotation angle ± 15°
hand shower Euphoria 110 Massage (27 239)
3 spray patterns: Rain, SmartRain, Massage
adjustable in height with gliding element
Silverflex shower hose 1750 mm (28 388)
GROHE EasyReach tray
GROHE TurboStat compact cartridge with wax thermoelement
GROHE SafeStop safety button at 38°C
GROHE SafeStop Plus optional temperature limiter at 43°C included
GROHE DreamSpray perfect spray pattern
GROHE StarLight chrome finish
GROHE SprayDimmer (stepless flow rate reduction)
GROHE EcoJoy 9.5 l/min flow limiter
SpeedClean anti-lime system
Inner WaterGuide for a longer life
Twistfree to prevent hose from twisting
suitable for instantaneous heaters from 18 kW/h
minimum flow rate 7 l/min
professional edition

Object Data

1 Revision

Last Updated

02/03/2022

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co/products/grohe-euphoria-310-shower-system-26849000/document/object-user-guide
Accessibility Performancen/a
Assembly CodeC1030
Asset TypeFixed
BIM Object NameGrohe_Euphoria_System_310_ShowerSystem_26849000
Classification NameUniclass2015
Classification ValuePr_40_20_87_81
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorChrome
Constituentsn/a
Cradle To Cradle Certificationn/a
Created Byinfo-uk@grohe.com
Created On2022-03-02T:09:00:00
CW ConnectionYes
Default Elevation1100.0 mm
Descriptionconsisting of: horizontal swivable 450 mm shower arm exposed thermostat with Aquadimmer function allows change between: head shower Rainshower Mono 310 (26 562) spray pattern: GROHE PureRain with ball joint, rotation angle ± 15° hand shower Euphoria 110 Massage (27 239) 3 spray patterns: Rain, SmartRain, Massage adjustable in height with gliding element Silverflex shower hose 1750 mm (28 388) GROHE EasyReach tray GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C included GROHE DreamSpray perfect spray pattern GROHE StarLight chrome finish GROHE SprayDimmer (stepless flow rate reduction) GROHE EcoJoy 9.5 l/min flow limiter SpeedClean anti-lime system Inner WaterGuide for a longer life Twistfree to prevent hose from twisting suitable for instantaneous heaters from 18 kW/h minimum flow rate 7 l/min professional edition
Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/100000/100000/100000/100200/100260/100261/100261984/1280/100261984.jpg
Documentation Certificateswww.bimstore.co/products/grohe-euphoria-310-shower-system-26849000/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grohe-euphoria-310-shower-system-26849000/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grohe-euphoria-310-shower-system-26849000/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grohe-euphoria-310-shower-system-26849000/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grohe-euphoria-310-shower-system-26849000/document/technical-data-sheet
Duration UnitYear
EcojoyNo
EF00063410.00
EF002169Other
EF002286External thread
EF002671Chrome
EF005084Wall
EF006974Thermostatic
EF0207851/2 inch
EF022168Yes
EF023051Mechanical
EF0230610.5 Pa
EF023686Aluminium
EF023957Yes
EF0250920
EF0250978.5
Expected Life0
Featuresn/a
FinishChrome
Full Recyclability Of PlasticAll plastic components are fully recycable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
HW ConnectionYes
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Installation Videon/a
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
MaterialOther
Model26849000
Model Number26849000
Model ReferenceShower system with thermostat for wall mounting
NBS DescriptionShower mixers
NBS Noten/a
NBS Object NameGrohe - Shower mixers
NBS Office Master Tagn/a
NBS Reference45-35-70/335
Nominal Depth0.0 mm
Nominal Height0.0 mm
Nominal Length0.0 mm
Primary MaterialGrohe - Chrome
Product Descriptionconsisting of: horizontal swivable 450 mm shower arm exposed thermostat with Aquadimmer function allows change between: head shower Rainshower Mono 310 (26 562) spray pattern: GROHE PureRain with ball joint, rotation angle ± 15° hand shower Euphoria 110 Massage (27 239) 3 spray patterns: Rain, SmartRain, Massage adjustable in height with gliding element Silverflex shower hose 1750 mm (28 388) GROHE EasyReach tray GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C included GROHE DreamSpray perfect spray pattern GROHE StarLight chrome finish GROHE SprayDimmer (stepless flow rate reduction) GROHE EcoJoy 9.5 l/min flow limiter SpeedClean anti-lime system Inner WaterGuide for a longer life Twistfree to prevent hose from twisting suitable for instantaneous heaters from 18 kW/h minimum flow rate 7 l/min professional edition
Production Year2022
Product Number26849000
Product Short TextShower system with thermostat for wall mounting
Product TypeShower System
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
TPI Document Linkcdn.cloud.grohe.com/tpi/2000/2100/2170/2178/2178290/original/2178290.pdf
Type CommentsShower system with thermostat for wall mounting
Type NameShower system with thermostat for wall mounting
URLwww.grohe.co.uk/en_gb/
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
