Flat Roof System - Single

by Keylite Roof Windows

Download Add to collection

Description

Keylite Flat Roof System

Many properties have extensions with flat, or almost flat roofs. Keylite has developed a Flat Roof System specifically for this application, which allows daylight into the area beneath. The Keylite Flat Roof System provides all the benefits of natural ventilation and daylight. All roof windows within the entire Keylite range can be integrated within a Flat Roof System. The Keylite Flat Roof System is designed to complement the Keylite Roof Windows overhead, and are suited to any property.

Click here to visit Keylite Roof Windows for more information.

Object Data

2 Revision

Last Updated

18/03/2024

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Technical Data Sheet

Product Data Sheet

Object metadata

_Authorinfo@keyliteuk.com
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Byinfo@keyliteuk.com
_Current Revision86
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/flat-roof-system-single/document/object-user-guide
2D Detailwww.keyliteroofwindows.com/architects/cad-drawings/
Accessibility Performancen/a
AccessoryKeylite - Metal - Aluminium
Acoustic Performance32
Air PermeabilityClass 3
Analytic Construction<None>
Assembly CodeB3020100
Asset TypeFixed
BIM Object NameKeylite_Window_FlatRoofSystem_FRS01
Classification NameUniclass2015
Classification ValueSs_30_30_72_72
Code Performancen/a
Colorn/a
Constituentsn/a
Construction WoodKeylite - Wood - Pine
Created Byinfo@keylite.co.uk
Created On19-05-2021 T09:00:00
Define Thermal Properties bySchematic Type
DescriptionMany properties have extensions with flat, or almost flat roofs. Keylite has developed a Flat Roof System specifically for this application, which allows daylight into the area beneath. The Keylite Flat Roof System provides all the benefits of natural ventilation and daylight. All roof windows within the entire Keylite range can be integrated within a Flat Roof System. The Keylite Flat Roof System is designed to complement the Keylite Roof Windows overhead, and are suited to any property.
Documentation Certificateswww.bimstore.co/products/flat-roof-system-single/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/flat-roof-system-single/document/installation-guide
Documentation Literaturewww.bimstore.co/products/flat-roof-system-single/document/product-literature
Documentation Maintenancewww.bimstore.co/products/flat-roof-system-single/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/flat-roof-system-single/document/technical-data-sheet
Duration UnitYear
Expected Life0
External PartsKeylite - Metal - Aluminium
FeaturesAn insulated timber up-stand; FRS flashings to integrate the window onto the timber up-stand; Ideal solution for Warm Roof applications below 15°; Combine with your choice of Keylite roof windows (priced separately) for a complete ready to install solution.
Finishn/a
Graden/a
Height1000.00 mm
Height CP780.00 mm
Ifc Export AsIfcWindow
Ifc Export TypeIfcWindowTypeEnum.WINDOW
Impact ResistanceClass 2
Internal PartsKeylite - Plastic - Laminate - Ivory
KeynoteL10
Light Transmittance0.85
ManufacturerKeylite
Manufacturer NameKeylite
Materialn/a
ModelSingle Flat Roof System
Model NumberFRS 01
Model ReferenceSingle Flat Roof System
NBS DescriptionRooflight systems
NBS Object NameKeylite - Rooflight systems
NBS Office Master Tagn/a
NBS Reference20-25-75/170
Nominal Depth1000.00 mm
Nominal Height0.00 mm
Nominal Length530.00 mm
Picture Typewww.keyliteroofwindows.com/products/roof-windows/flat-roof-system/
Production Year2021
Referenced Standardn/a
Replacement Costn/a
Resistance To Snow Load4H-20, Ar-4TM
Resistance To Wind LoadClass C4
Shapen/a
Size530mm(W) x 1000mm(H)
Solar Factor G0.65
Spare Partsn/a
Thermal Transmittance Of Glass1.1
Thermal Transmittance Of Window1.3
Type CommentsFRS 01
Type NameFRS 01
URLwww.keyliteroofwindows.com/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts10
Warranty Duration UnitYear
Warranty Guarantor Laborinfo@keyliteuk.com
Warranty Guarantor Partsinfo@keylite.co.uk
Water TightnessE1050
Width530.00 mm
Width CP550.00 mm
WoodKeylite - Wood - Pine
Wooden BoardingKeylite - Bitumen/Asphalt
