Recoup Easyfit+

by Recoup Energy Solutions

Download Add to collection

Description

The Recoup Easyfit+ is a stand-alone horizontal WWHRS system designed to slide directly under a standard bath or a walk-in riser shower tray. Easy to retrofit into an existing system or plan into any property design. This waste water heat recovery system will produce efficiencies of up to 47.6%. The Recoup Easyfit+ is a very exciting product for the residential retrofit, new-build apartment & social housing markets. SAP listed, easy to install, legionella control risk assessed and virtually maintenance free. The Recoup Easyfit+ offers a combination of price point, efficiency, and ease of installation that has not previously been possible.

Unapproved

This content has not yet been through the Bimstore QA process and as such may not meet our minimum standards for content hosting.

Object Data

2 Revision

Last Updated

05/12/2023

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co
_Current Revision2
_Distributed Bywww.bimstore.co
Accessibility Performancen/a
Assembly CodeD2090
Asset TypeFixed
BIM Object NameRecoupEnergySolutions_PlumbingFixtures_WastewaterHeatExchanger_Easyfit+
Classification NameUniclass2015
Classification ValuePr_60_60_36_94
Code Performancen/a
ColorBlack, White
Constituentsn/a
Created Byinfo@recoup.co.uk
Created On2023-10-30 T09:00:00
CW ConnectionYes
Default Elevation0.00 mm
DescriptionThe Recoup Easyfit+ is a stand-alone horizontal WWHRS system designed to slide directly under a standard bath or a walk-in shower tray. Easy to retrofit into an existing system or plan into any property design. This waste water heat recovery system will produce efficiencies of up to 47.6%. The Recoup Easyfit+ is a very exciting product for the residential retrofit, new-build apartment & social housing markets. SAP listed, easy to install, legionella control risk assessed and virtually maintenance free. The Recoup Easyfit+ offers a combination of price point, efficiency, and ease of installation that has not previously been possible.
Documentation Certificatesrecoup.co.uk/products/easyfit/
Documentation Installation Guidewww.bimstore.co/products/easyfit/document/installation-guide
Documentation Literaturewww.bimstore.co/products/easyfit/document/product-literature
Documentation Maintenancerecoup.co.uk/products/easyfit/
Documentation Technicalrecoup.co.uk/products/easyfit/
Duration UnitYear
Expected Life25
Features- Horizontal system designed to fit under a standard bath - KIWA validated efficiencies of up to 47.6%, dependant on flow rate - WRAS Approved - Can be retrofitted into an existing system - Legionella control risk assessed - Option of 3 system installation variations - High quality manufacture - Virtually maintenance free - SAP listed
FinishBlack ABS
Full Product Weight9.70 kg
Graden/a
HW ConnectionYes
Ifc Export AsIfcHeatExchangerType
Ifc Export TypeNOTDEFINED
KeynoteS12
Mains&Preheated Water Connection1/2" male BSP
Mains Water Volume0.87 L
ManufacturerRecoup Energy Solutions Ltd
Manufacturer NameRecoup Energy Solutions Ltd
MaterialCopper, ABS
Maximum Mains Water Inlet Pressure10.00 bar
Maximum Mains Water Working Temperature85 °C
Minimum Mains Water Inlet Pressure1.00 bar
ModelRecoup Easyfit+
Model NumberHorizontal waste water heat exchanger
Model ReferenceRecoup Easyfit+
NBS DescriptionPassive heat exchangers
NBS Noten/a
NBS Object NameRecoup - Passive heat exchangers
NBS Office Master Tagn/a
NBS Reference90-45-45/360
Nominal Depth0.00 mm
Nominal Height0.00 mm
Nominal Length0.00 mm
Production Year2023
Product URLeasyfit.recoup.co.uk
Referenced Standardn/a
Replacement Costn/a
ShapeRectangular
Shower Flow Rate Range5 - 20 L/min
Sizen/a
Spare Partsn/a
Type CommentsHorizontal waste water heat exchanger
Type NameRecoup Easyfit+
UPINdoi.org/10.21/ZHNNDRQX
URLrecoup.co.uk/
Vent ConnectionNo
Warranty DescriptionThe RECOUP Easyfit+ comes with a 2 year warranty unless agreed otherwise. This starts from either the date of invoice from Recoup Energy Solutions Ltd or purchase from partnered trade distributors. Installation registration should be completed as part of the guarantee requirements. This warrantly is conditional on the product being installed in accordance with these instructions (Installation and ALL requirements for SAP, if product is to be recognised for Energy efficiency calculations), correct plumbing practices and Building Regulations.
Warranty Duration Labor0
Warranty Duration Parts5
Warranty Duration UnitYear
Warranty Guarantor Laborn/a
Warranty Guarantor Partsinfo@recoup.co.uk
Waste ConnectionYes
Waste Water Connection40 - 43 mm
