Double Vertical Bi-Lite - DVBL
Description
Vertical Bi-Lite
Roof Windows
Keylite Vertical Bi-Lite (VBL) Roof Windows are the ideal way to maximise the light and ventilation into any room.
Keylite VBL roof windows are available in a variety of styles and combinations. Arranging your Keylite Roof Windows to incorporate a Keylite VBL creates a larger glazed area, and increases light into your living area.
The roof and vertical windows combine seamlessly at eaves level.
For “tilt and turn” prices and options, contact the Keylite Sales Team.
Standard vertical windows are available as tilt only.
Keylite VBL’s are designed to complement the Keylite Roof Windows overhead, and are suited to any property.
Roof Window Sizes
| Window Size | 780mm Wide | 1570mm Wide | 2370mm Wide |
| Pine Finish | |||
| H = 600mm tilt only | VBL-780X600-T | DVBL-780X600-T | TVBL-780X600-T |
| H = 950mm tilt only | VBL-780X950-T | DVBL-780X950-T | TVBL-780X950-T |
| H = 950mm tilt+turn | VBL-780X950-TT | DVBL-780X950-TT | TVBL-780X950-TT |
| White Finish | |||
| H = 600mm tilt only | WF-VBL-780X600-T | WF-DVBL-780X600-T | WF-TVBL-780X600-T |
| H = 950mm tilt only | WF-VBL-780X950-T | WF-DVBL-780X950-T | WF-TVBL-780X950-T |
| H = 950mm tilt+turn | WF-VBL-780X950-TT | WF-DVBL-780X950-TT | WF-TVBL-780X950-TT |
Object Data
1 Revision
Last Updated
11/10/2022
Available Software
BS1192:4
Compliant
BSB
Compliant
EPD
Not Available
Sustainability & Environmental Data
Not available.
Environmental Product Declarations
There are no EPDs.
