Heritage 2800 French Door (F1 - Open Out)

by Deceuninck

Download Add to collection

Description

The Deceuninck 2800 French and Residential Door System is engineered with its sculptured profile and robust construction, the 2800 system delivers outstanding thermal insulation, security, and long-term durability. It integrates seamlessly with the 2800 Window Suite.

Key features:

Heritage aesthetic.

Doc L compliant.

Doc M compliant.

Doc Q compliant.

Kitemark Certified.

Accommodate a large range of IGU thicknesses for commercial specification.

30+ foil options from stock.

Energy ratings

As high as A with Triple Glazing

As high as B with Double Glazing

U-Value

As low as 0.91 with triple glazing

As low as 1.2 with double glazing

Object Data

1 Revision

Last Updated

27/02/2025

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Literature

Product Data Sheet

Product Literature

Object metadata

_AuthorDeceuninck Ltd
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bydeceuninck.ltd@deceuninck.com
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/415f5df2-57c4-4cc7-88d7-ee97d28bf6e4/document/object-user-guide
Accessibility PerformanceDoc M Compliant
Accessoriesn/a
Accessory OptionsHead drip, weather bar, architrave finishing trims, Georgian bars, Leaded lights
Acoustic Rating32-43 dB
Analytic Construction<None>
Architraves Finishn/a
Architraves Finish OptionsWhite - RAL 9016 (standard), Laminated foil, Decoroc colour (RAL)
Architraves MaterialPVC-UE
Asset TypeFixed
Beam Radiation Transmittance0
BIM Object NameDeceuninckLtd_PVCUDrsts_Heritage2800FrenchDoor_F1_OpenOut
Classification NameUniclass2015
Classification ValuePr_30_59_24_92
Code PerformanceBS 6375, BS 7412, BS EN 12608, PAS24
Colorn/a
ConfigurationDouble leaf, single action
Constituentsn/a
Construction TypePLASTIC
Created Bydeceuninck.ltd@deceuninck.com
Created On2025-02-27T09:00:00
Define Thermal Properties bySchematic Type
DescriptionFrench doorset
Documentation Certificateswww.bimstore.co/products/415f5df2-57c4-4cc7-88d7-ee97d28bf6e4/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/415f5df2-57c4-4cc7-88d7-ee97d28bf6e4/document/installation-guide
Documentation Literaturewww.bimstore.co/products/415f5df2-57c4-4cc7-88d7-ee97d28bf6e4/document/product-literature
Documentation Maintenancewww.bimstore.co/products/415f5df2-57c4-4cc7-88d7-ee97d28bf6e4/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/415f5df2-57c4-4cc7-88d7-ee97d28bf6e4/document/technical-data-sheet
Door Leaf Colour OptionsWhite - RAL 9016 (standard), Laminated foil, Decoroc colour (RAL)
Door Leaf CoreGalvanized steel
Door Leaf MaterialPVC-U with glazing
Door Leaf Panel Detailsn/a
Door Leaf Perimeter SealsHigh-performance integral multifunctional seal/ gasket
Door Leaf Thickness70 mm
Duration UnitYears
Environmental Product Declarationn/a
Expected Life35
Featuresn/a
Fill GasArgon
Finishn/a
Fire Ratingn/a
Fire ExitNo
Fire Ratingn/a
Frame/Mullion MaterialConcept
Frame AccessoriesTrickle ventilator
Frame Colour OptionsWhite - RAL 9016 (standard), Laminated foil, Decoroc colour (RAL)
Frame Installation FastenersThrough frame fasteners, Fixing lug
Frame MaterialsGalvanized steel core with PVC-U sleeve
Frame Perimeter Seals Or InsertsImpregnated foam seal/tape, Flexible membrane
Frame ProfileDecorative
Frame Size Options70 mm, 85 mm
Frame Thickness70.00 mm
Frame Threshold Options2892 55mm Frame, 2833 70mm Frame, 2976 (Stormgaurd AM3-70 open-in), 2977 (Stormgaurd AM5EX-70 open-out)
Frame Ventilator OptionsNot required, Proprietary ventilation device
FunctionInterior
Glass Colourn/a
Glass Layers2
Glass Thickness 14.00 mm
Glass Thickness 24.00 mm
Glass Thickness 30.00 mm
Glazing Area Fraction0
Glazing Beading Location OptionsInternal
Glazing Beading Type OptionsDecorative 28mm (standard), other styles available for other glazing thicknesses
Glazing Manifestationn/a
Glazing Panel MaterialGlass_Double
Glazing Thickness Options3-40 mm
Graden/a
Handicap AccessibleYes
Hardwaren/a
Height2100.00 mm
Ifc Export AsIfcDoorType
Ifc Export TypeDOOR
Infiltration0
Installation FastenersThrough frame fasteners, Fixing lug
Is CoatedYes
Is ExternalYes
Is LaminatedNo
Is TemperedNo
Is WiredNo
Leaf MaterialConcept
Leaf Thickness70.00 mm
Manufacturerdeceuninck.ltd@deceuninck.com
Manufacturer NameDeceuninck Ltd
MaterialPVC-U
ModelHeritage 2800 French Door - F1
Model Numbern/a
Model ReferenceHeritage 2800 French Door - F1
Mullion Width68.00 mm
NBS DescriptionPVC-U doorsets
NBS Noten/a
NBS Object NameDeceuninck Ltd - PVC-U doorsets
NBS Office Master Tagn/a
Nominal Depth1980.00 mm
Nominal Height2100.00 mm
Nominal Length0.00 mm
Opening OptionsOpen out
OperationDOUBLE_DOOR_SINGLE_SWING
Outer Frame Height2095.00 mm
Outer Frame Width1970.00 mm
Performance Intruder Resistance Accessibilityn/a
Performance Intruder Resistance Applicationn/a
Performance Intruder Resistance Conformityn/a
Performance Intruder Resistance Minimum RequirementIn accordance with BS 6375-3
Performance Strength And DurabilityIn accordance with BS 6375-3
Performance Surface Spread Of Flamen/a
Perimeter SealsHigh-performance integral multifunctional seal/ gasket
Production Year2025
Referencen/a
Referenced Standardn/a
Reflectivity0
Replacement Costn/a
Security RatingPAS 24
Self ClosingNo
Shapen/a
Sill Options3337 - 95 mm sill, 3338 - 150 mm sill, 3339 - 180 mm sill, 367 - 250 mm sill
Sizen/a
Smoke StopNo
Solar Heat Gain Transmittance0
Spare Partsdeceuninck.ltd@deceuninck.com
Structural Opening Height2100.00 mm
Structural Opening Width1980.00 mm
Structural Tolerance Head5.00 mm
Structural Tolerance Jamb5.00 mm
Thermal Transmittance0.97
Thermal Transmittance Summer0
Thermal Transmittance Winter0
Third Party AccreditationBSI Kitemark
Threshold Width1830.00 mm
Translucency0
Transom Mullion Size Optionsn/a
Type CommentsHeritage 2800 French Door - F1
Type NameHeritage 2800 French Door - F1
Undercut7.00 mm
URLwww.deceuninck.co.uk/
Wall ClosureBy host
Warranty DescriptionManufacturer warranty
Warranty Duration Laborn/a
Warranty Duration Parts10
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partsn/a
Weather Performance Air PermeabilityTo BS 6375-1, Class 4 (600 Pa)
Weather Performance UK Exposure CategoryTo BS 6375-1, Class A3 (1200 Pa)
Weather Performance WatertightnessTo BS 6375-1, Class E1050 (1050 Pa)
Width1980.00 mm

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
