Airgap 6000

Description

The Fluidmaster AirGap™ 6000 series are our revolutionary, next generation toilet cistern fill valves. They do everything the best-selling 400 series does, but with great new features.

TECHNICAL DATA

• Part Number: 6420-D-001
• Product Description: Bottom Entry Delayed Fill Airgap™ Valve
• WRAS Approval: 2006332
• Applied Standard(s): BS 1212-4:2016
• Material(s): ABS, Brass, EPDM, POM, PP, PVC
• Approx. Weight: 0.320 kg
• Product Dimensions: Lx100mm Wx55mm H: Adjustable from 292mm to 345mm (Thread 50mm)
• Product Type: Part 4 Compact Type Fill Valve
• Operating pressure Range - From 0.1bar to 10bar mains water pressure.
• Airgap distance built in design to meet AUK1 and Type AG airgap requirements.
• Meets requirements of the Water Supply (Water Fittings) Regulations, Byelaws in Scotland, as they apply to
• Type AG and Type AUK1 air gaps in WC suites and the interim agreement.
• BS1212-4 2016 Compliant.
• Reduces risk of water hammer.
• Delayed fill for saving water.
• Quiet Filling - Noise level below 60dB (Normal Conversation 60-70dB).
• Pressure restrictor fitted to control flow rates when not using gravity systems- See instructions for details.
• Removable filtration - Filter fitted within thread.
• Small foot print allows for fitting into tight cisterns.
• Adjustable Height - From 268mm to 318mm. (Overall Height of valve)
• Water level adjustment from approx. 163mm to 218mm
• Normal Working Temperature – 0°C – 20°C.
• Inlet Thread – Brass ½” BSP to suit tap connector: 50mm Long
• Made From Recyclable Materials.
